10.038 Bobst Alpina 110 II A3 MOT

Manufacturer:  Bobst
Machine type: Folder Gluer
Model:  Alpina 110 II A3 MOT
Year of construction: 2004 / 2025

Location: D-75433 Maulbronn, nearest airport Stuttgart
Size:  max. 1100 mm, min. 66 mm
Equipment:  straight line, lock bottom, double wall, 4+6 point gluing, electronic upper gluing system HHS X-tend³, 8 channel with 6 guns, equipped with following additional modules for quality control: code reader / disc glue control / glue gun control / linear ejector control, lower disc gluing station left, feeder with vibrator, tooth gauge and vacuum, aligning section right & left after feeder, pre break module with central transport, new electronic servo back folding (Stöber) with touch screen and program memory, new remote control, digital read out units, motorized size adjustment, central transport in folding, 2 x motorized height adjustable tool holder, press device after folding, kicker, counter, video control in transfer station, 2 x box aligner control unit at press station, completely new Siemens control with touch screen, new frequency converter, new electronic components, rebuilt 2025.
Reconditioning 2025: Machine is equipped with completely new Siemens SPS S7-1500 control und Siemens touch screen, the whole electric cabinet is new, new servo backfolding with Stöber servo drive and touch screen panel with program memory. New frequency converter SEW, all drive motors are rebuilt
Others: After arrangement machine can be inspected in running condition and will be delivered completely rebuilt, all bearings and belts are new.
Available: approx. May 2025
Delivery: FCA / Free Carrier
