10.035 Jagenberg Diana 125-3

Manufacturer: Jagenberg
Machine type: Folder Gluer
Model:  Diana 125-3
Year of construction: 1991
Location: D-75433 Maulbronn, nearest airport Stuttgart
Size:  max. 1350 mm, min. 45 mmm
Equipment:  straight line, lock bottom, double wall, 4 + 6 point gluing, electronic upper gluing system HHS, 4 channels with 4 guns,  high pressure, lower disc gluing system left, electronic back folding via servos, extended folding station, module 150, pre breaker right and left, kicker, counter, vibrator at feeder, digital read out unit, motorized tuck in station, motorized transfer station, additional middle transport in folding station, vacuum at back folding, video control, DBS 01 control, fully automatic format adjustment Jagset II, pneumatic, controlled press station
Reconditioning 2023: checked, cleaned, repainted and new feeder- and transport belts.   Others: Machine can be inspected in running condition after arrangement
free from: after arrangement
Delivery: FCA / Free carrier
